If you are looking for a custom fence trailer that is both durable and meets your specific needs, our custom fence trailer is the perfect choice. These trailers are specially designed for transporting fence materials, posts, and tools, ensuring easy operation and efficient use.
Our trailers are made of high-quality steel and have been reinforced in design to withstand heavy loads, making them an ideal choice for contractors, construction companies, and agricultural enterprises. Custom design offers a variety of sizes and configurations, suitable for different types of fence materials, whether for residential, commercial, or industrial projects.
- Why choose our custom fence trailer?
Durable structure: Made of high-quality steel, it can withstand harsh working environments and poor road conditions. - Customization options: We offer a variety of sizes and functional choices, ranging from multiple axles to adjustable heights. You can customize the trailer according to your specific needs.
- Efficient loading and unloading: Our fence trailer is designed for easy operation, helping you complete loading and unloading tasks more quickly and saving time and effort.
- Affordable prices: We offer factory-direct sales prices. When customizing fence trailers, we ensure quality while providing you with the most cost-effective choice.
Whether you need to transport large coils of wire fences, wooden posts, or other building materials, our custom fence trailers can provide you with reliable transportation solutions, making your work more efficient.
Contact us to learn more about our custom fence trailers.
|
Trailer Parameters |
|||
| Product Name | 2 axles fence semi trailer | 3 axles fence semi trailer | 4 axles fence semi trailer |
| Size | 9500/11000*2500*2800/3800 (mm) | 12500/13000*2500*2800/3800 (mm) | 12500/13000*2500*2800/3800 (mm) |
| Payload | 30-60Ton | 30-80Ton | 40-100Ton |
| Axles | 2*13T/16Ton/ FUWA/BPW/Other | 3*13T/16Ton FUWA/BPW/Other | 4*13T/16Ton FUWA/BPW/Other |
| Main beam | Height: 500mm, upper plate is 12mm, middle plate is 6mm, down plate is 14mm; Material is Q345B Steel. (optional T700) | Height: 500mm, upper plate is 16mm, middle plate is 10mm, down plate is 18mm; Material is Q345B Steel. (optional T700) | Height: 500mm, upper plate is 18mm, middle plate is 12mm, down plate is 20mm; Material is Q345B Steel. (optional T700) |
| Side Wall Height | 600mm-1700mm (can be customized) | ||
| Side beam | 16mm channel steel (Material is Q235B steel, optional Q345/T700 ) | ||
| Bottom Platform | 3mm chequered steel plate | ||
| Suspension | Leaf spring suspension /Air suspension optional | ||
| Leaf spring | 90(width)mm*13(thickness)mm*10 layer(especial for exporting market) | ||
| Tire | 12R22.5 / 11.00R20 – 8/12pcs (Other size optional) | ||
| Rim | 9.00-22.5 / 11.00R20 – 8/12pcs (Other size optional) | ||
| Kin pin | Jost brand 2.0 or 3.5 inch | ||
| Landing gear | Jost brand 28Ton two-speed | ||
| Braking system | Wabco re 6 relay valve; T30/30+T30 spring brake chamber; two units of 45L air tanks | ||
| Electrical | LED light, 7 ways,24V | ||
| Tool box | One piece 1m *0.5m*0.5m ( size can be customized) | ||
| Twist locks | Optional | ||
| ABS | Optional | ||
| Painting | 1. Sand blasting processing clean rust.
2. Coat of anticorrosive primer. 3. Coats of finish urethane paint. 4. Color as customer choice. |
||
OUR FACTORY
SINOHENG Trailer Factory is an enterprise specializing in the production and sales of trailers, dedicated to providing customers with high-quality and high-performance trailer products. We use high-strength steel and optimized design to ensure that the products maintain high load-bearing capacity while being lightweight, meeting customers’ dual demands for transportation efficiency and cost control.
Our products are not only popular across the country but also exported in bulk to over 30 countries and regions in Southeast Asia, Africa, the Middle East, South America, etc., earning the trust of customers worldwide. Moreover, we offer comprehensive after-sales service to ensure you have no worries. Choosing SINOHENG means choosing quality, choosing professionalism, and choosing peace of mind.
