If you are looking for a reliable structure, strong load-bearing capacity, and high-cost performance flatbed trailer for sale, this 40-foot three-axle flatbed semi-trailer is a very worthy choice to consider.
The vehicle is 40 feet in length. The chassis is welded with high-strength steel and is capable of carrying 20-foot and 40-foot standard containers. It is also suitable for transporting most goods such as steel coils and concrete products. The three-axis design effectively distributes the load, enhancing the vehicle’s stability and safety at high speeds or in complex road conditions.
This trailer is equipped with high-quality tires, reinforced side beam structures, container locks, and a robust mechanical suspension system as standard, and still performs well in harsh transportation environments. The vehicle surface is coated with anti-corrosion paint, which extends its service life and reduces the cost of later maintenance.
Whether you are a logistics company, a construction carrier, or engaged in international trade transportation, our 40-foot flatbed trailer can offer you reliable performance and low operating costs. We can also customize the axle brand, tire model, color coating, and other configurations according to your needs.
As a reliable supplier of flatbed trailers, we offer factory-direct sales prices, fast delivery, and comprehensive after-sales service to help you efficiently expand your transportation business.
|
Trailer Parameters |
|
| Overall Dimension (mm) | Length×width×height:12,500×2,480xH1 (The height will be adjusted according to the tractor specification) |
| Fifth Wheel Height (mm) | The height will be adjusted according to the tractor’s specifications |
| Tare Weight (kg) | 7,700 kg（±5%） |
| Payload (kg) | 40,000 kg（±5%） |
| Gross weight (kg) | 47,700 kg（±5%） |
| Tire | Type: 12R22.5, equipped with 12 pieces per chassis, a famous brand from China, optioned by the factory |
| Rim | Type: 9.0-22.5, equip 12pcs per chassis |
| Axle | FUWA 13T, 3 sets, without ABS |
| Suspension | 3-axles enforced mechanical suspension |
| Landing Gear | 30T |
| Kingpin | JOST 3.5”, exchanged |
| Brake System | 30/30 type on rear two axles, WABCO brake valve |
| ABS | Without |
| Electrical System | 24V, LED lamp |
| Spare Tire Carrier | Equip 2 sets per chassis |
| Tool Box | 1 set |
| Lock | 12pcs |
| Paint | Primer + top coat, polyurethane paint |
| Color | By the customer’s requirement. |
OUR FACTORY
SINOHENG Trailer Factory is an enterprise specializing in the production and sales of trailers, dedicated to providing customers with high-quality and high-performance trailer products. We use high-strength steel and optimized design to ensure that the products maintain high load-bearing capacity while being lightweight, meeting customers’ dual demands for transportation efficiency and cost control.
Our products are not only popular across the country but also exported in bulk to over 30 countries and regions in Southeast Asia, Africa, the Middle East, South America, etc., earning the trust of customers worldwide. Moreover, we offer comprehensive after-sales service to ensure you have no worries. Choosing SINOHENG means choosing quality, choosing professionalism, and choosing peace of mind.
