Looking for a reliable heavy-duty transport trailer? Our Lowboy Trailer is specially designed for transporting heavy equipment, construction machinery, and bulk goods. It is available in 2-axle, 3-axle, and 4-axle configurations, capable of carrying extremely heavy loads and ensuring the stability of long-distance transportation.
This Lowboy Trailer is made of high-strength steel and equipped with reinforced axles. It is specially designed for transporting heavy machinery such as excavators and bulldozers. The low-bed design ensures that even goods of considerable height can safely pass through Bridges and narrow sections, greatly enhancing transportation efficiency and safety.
We offer factory-direct prices, allowing you to obtain high-quality trailers at the most competitive prices. Whether it’s a single unit customization or a large order, we can provide customized configurations tailored to your specific transportation needs.
Product highlights:
- High load-bearing capacity – can carry 80 tons or more, depending on the configuration of the number of shafts
- Customized axle count configuration – Available in 3-axle, 4-axle, 5-axle, or 6-axle configurations to ensure the best weight distribution
- Low bed design – specifically designed for transporting tall goods
- Heavy-duty structure – Made of high-quality steel to ensure durability
- Factory direct sales price – No middlemen, ensuring more competitive prices
- Fast global delivery – Providing reliable global transportation services
Choose our Lowboy Trailer. Whether it’s the transportation of construction equipment, mining machinery, or heavy agricultural equipment, we can provide the most suitable solutions. Contact us immediately to get a customized quotation and technical support!
|
Trailer Parameters |
|||
| Product Name | 2 axles lowboy trailer | 3 axles lowboy trailer | 4 axles lowboy trailer |
| Size（mm） | 12500*3000*1100 | 13000*3000*1100 | 14000*3000*1100 |
| Payload | 40000KG | 60000KG | 80000KG |
| Axles | 2 * 13ton capacity (Brand optional) |
3 * 13ton capacity (Brand optional) |
4 * 13ton capacity (Brand optional) |
| Landing gear | 28-ton two-speed | ||
| Ladder | Hydraulic ladder or Mechanical spring ladder | ||
| Leaf spring | 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets) |
||
| Main beam | Height: 500mm, upper plate is 16mm, middle plate is 8mm, down plate is 18mm ; Material is Q345B Steel. |
||
| Side beam | 250mm I beam; 20mm channel steel ( Material is Q235steel ). | ||
| Bottom Platform | 4mm thickness diamond steel plate | ||
| Suspension | Mechanical suspension (Air suspension optional) | ||
| Braking system | Double air chamber, brake valve,45L air tanks; ABS optional | ||
| Electrical | LED light, 7 ways,24V | ||
| Rim | 9.00-22.5 / 11.00R20 8pcs (Other size optional) | ||
| Kin pin | 2’’/3.5’’ bolt type | ||
| Accessory | One tooling box with a set of standard trailer tools | ||
| Painting | 1. Sand blasting processing cleans rust. 2. Coat of anticorrosive primer. 3. Coats of finish urethane paint. 4. Color as customer choice. |
||
OUR FACTORY
SINOHENG Trailer Factory is an enterprise specializing in the production and sales of trailers, dedicated to providing customers with high-quality and high-performance trailer products. We use high-strength steel and optimized design to ensure that the products maintain high load-bearing capacity while being lightweight, meeting customers’ dual demands for transportation efficiency and cost control.
Our products are not only popular across the country but also exported in bulk to over 30 countries and regions in Southeast Asia, Africa, the Middle East, South America, etc., earning the trust of customers worldwide. Moreover, we offer comprehensive after-sales service to ensure you have no worries. Choosing SINOHENG means choosing quality, choosing professionalism, and choosing peace of mind.
